For the proper operation of the garden irrigation system, a water source with the following parameters is required: dynamic pressure of 3.0 bar, water flow: 0.8 m³/h.
If you don’t know how to check the water quantity and dynamic pressure, watch the #AquaSet video. If you need measuring tools, take a look at our offer.

To make the installation of the irrigation system easier, we provide you with a detailed manual with QR codes. These give you quick access to video materials and additional assembly tips that guide you step by step through the entire installation process. This offers you comprehensive support from our side to ensure smooth and trouble-free assembly.

The garden irrigation system includes the necessary components for:

• A pop-up sprinkler system for the lawn, and

• A drip irrigation system for hedges, beds, or vegetable patches.

If the water source parameters are met, the garden irrigation system is divided into 3 sections.
Each section is independently activated by an internal Hunter irrigation controller. The controller sends signals to the electric valves, which are activated in sequence according to the set schedule.

The irrigation plan includes the use of Hunter Pro-Spray PROS-04 pop-up sprinklers, optimally positioned to ensure even watering of the lawn, with a total of thirteen of these sprinklers.

The irrigation system for the plants in the garden is based on drip irrigation using pressure-compensated drip lines, where the drippers are arranged every 0.33 m and adjusted to the position of the plants.

The automatic garden irrigation system consists of the following components:

• Hunter X-CORE 4-Zone Indoor Irrigation Controller:
  This controller automates the entire irrigation process. The user-friendly device is intended for indoor installation, where it is not exposed to the weather.
  The controller requires a 230V power supply. It is connected to the electric valves via a signal cable, through which a 24V signal (safe voltage) is sent to the valve solenoids to activate the individual sections of the irrigation system.

• Rain Bird 100-HV Electric Valves:
  The electric valves are installed in a special valve box, which protects them from mechanical damage and weather influences.
  The valve box is equipped with a PVC bottom. Typically, the valve box is installed near the water source.

Information for the Buyer

The irrigation system is adapted to the specified dimensions, the shape of the garden, and parameters such as the water source and dynamic pressure, to ensure optimal efficiency and functionality.
If the shape, size, or parameters of your garden differ from those described, we can create a custom solution for your needs.
Take a look at our “Custom Irrigation Projects” category and order a project that is perfectly tailored to your space.

If you have any questions or need further information, we are happy to help!

When purchasing a self-assembly irrigation kit, you will receive:

• A complete set of assembly materials

• A detailed irrigation plan

• Instruction manuals for each product

• A section layout plan

• A selection of suitable nozzles for the sprinklers
