To ensure the proper operation of the garden irrigation system, a water source with the following parameters is required:

• Dynamic pressure: 3.0 bar

• Water flow rate: 0.6 m³/h

If you’re unsure how to check the water flow and dynamic pressure, please refer to our #AquaSet video. If you need measuring tools, take a look at our available selection.

Easy Installation with Step-by-Step Instructions

To make installation easier, we provide a detailed manual with QR codes, giving you quick access to video materials and additional assembly tips. These resources guide you step-by-step through the entire installation process, offering full support from our side to ensure a smooth and hassle-free setup.

System Overview

The garden irrigation system includes all the necessary components for:

• A pop-up sprinkler system for lawns

• A drip irrigation system for hedges, flower beds, or vegetable gardens

If the water source parameters are met, the system is divided into 2 zones.
Each zone is independently activated by an internal Hunter control unit. The controller sends signals to the electric valves, which are activated in sequence according to the set schedule.

Irrigation Project Details

The irrigation design incorporates Hunter Pro-Spray PROS-04 pop-up sprinklers, strategically placed to ensure even coverage of the lawn. A total of four sprinklers are included.

For the plant areas in the garden, a pressure-compensated drip irrigation system is used, with drippers spaced every 0.33 meters and adapted to the position of the plants.

Components of the Automatic Irrigation System

• Hunter X-CORE Controller (Indoor, 4 zones):
  This user-friendly controller automates the entire irrigation process. Designed for indoor installation, it is protected from weather exposure. It requires a 230V power outlet. The controller is connected to the electric valves via a signal cable, sending a safe 24V signal to activate the solenoids and control each irrigation zone.

• Rain Bird 100-HV Electric Valves:
  These valves are installed in a special valve box with a PVC floor, which protects them from mechanical damage and weather conditions. The valve box is typically placed near the water source.

Important Information for Buyers

This irrigation system has been tailored to the specified dimensions, garden layout, and parameters such as water source and pressure to ensure optimal efficiency and performance.

If the shape, size, or parameters of your garden differ from those described, we can offer a custom solution to suit your needs. Visit our “Custom Irrigation Projects” category and order a project that fits your space perfectly.

Included in Your DIY Irrigation Kit

When you purchase this DIY irrigation set, you receive:

• A complete set of assembly materials

• A detailed irrigation plan

• User manuals for each component

• A zone division layout

• A selection of suitable sprinkler nozzles
